iTherm ® 280 Programmer’s Guide Programming Codes
28-07764 Rev C Page 115
ASCII [ESC] t or [ESC] [SUB] t
Hexadecimal 1BH 74H or 1BH 1AH 74H
Decimal <27><116> or <27><26><116>
IPCL &%PM
1
>
EPOS [ESC] L
Description This command activates page mode and sets the orientation.
This command may also be issued during page definition. When issued
in page mode it resets the orientation and entry position, but does not
cause the currently defined image to be erased or printed.
Where x = 0 for standard orientation (Direction A).
x = 1 for 270
°
Rotation (Direction B)
x = 2 for 180
°
Rotation (Direction C)
x = 3 for 90
°
Rotation (Direction D)
Receipt or
Inserted Form
B > > > > >
A > > > > >
D > > > > >
C > > > > >
Initial entry
location
Note 1: This command saves the current right and left margin and sets them to the
maximum values for the orientation currently defined.
Note 2: During page mode definition almost all printer commands are active. The
following table lists the exceptions.
Command Active Action
Cash drawer
commands Yes Immediate action
Bell command Yes Immediate action
Auto cut commands Delayed The printer will perform a feed to cut and then operate the auto
cutter after the page is printed. The cut command may be
anywhere in the definition. If the page is printed twice, the Auto
cut command must be reissued after the first print to generate
additional cuts.
Electronic journal No This command is like a station select and is not active. You
