Programming Codes
iTherm
®
280 Programmer’s Guide
Page 212
Rev C
28-07764
Bit
Off/On
Hex
Decimal
Status for Automatic Status Back (ASB)
0
Off
00H
<0>
Journal memory adequate
On
01H
<1>
Journal memory low (Less than 8K)
1
Off
00H
<0>
Paper low sensor: paper adequate
On
02H
<2>
Paper low sensor: paper low
2
Off
00H
<0>
Journal memory adequate
On
04H
<4>
Journal memory exhausted.
3
Off
00H
<0>
Paper out sensor: paper present
On
08H
<8>
Paper out sensor: paper not present
4
Off
00H
<0>
Not used; fixed to Off
5,6
-
-
-
Undefined
7
Off
00H
<0>
Not used; fixed to Off
Table 31 Automatic Status Back (ASB) Third Byte (Paper Sensor Information)
Bit
Off/On
Hex
Decimal
Status for Automatic Status Back (ASB)
0-3
-
-
-
Undefined
4
Off
00H
<0>
Not used; fixed to Off
5,6
-
-
-
Undefined
7
Off
00H
<0>
Not used; fixed to Off
Table 32 Automatic Status Back (ASB) Fourth Byte (Paper Sensor Information)
Function
Transmit Status
ASCII
[GS] r
Hexadecimal 1DH 72H
Decimal
<29> <114>
Range
1
≤
n
≤
2
49
≤
n
≤
50
Description The [GS] r
sensor status as one byte of data when
connector status when
for the paper sensor status is not transmitted because the printer goes off line
when a paper out is detected by the paper out sensor. The paper roll low sensor
is an option. If the sensor is not installed, bits 0 and 1 for the paper sensor status
are always in the “Paper adequate” status.
Bit
Off/On
Hex
Decimal
Status
0
Off
00H
<0>
Journal Memory adequate
On
01H
<1>
Journal Memory low (Less than 8K)
1
Off
00H
<0>
Paper low sensor: paper adequate
On
02H
<2>
Paper low sensor: paper low
2
Off
00H
<0>
Journal Memory adequate
On
04H
<4>
Journal Memory exhausted.
3
Off
00H
<0>
Paper out sensor: paper present
On
08H
<8>
Paper out sensor: paper not present
4
Off
00H
<0>
Not used; fixed to Off
5,6
-
-
-
Undefined
7
Off
00H
<0>
Not used; fixed to Off
Table 33 Paper Sensor Status (
