TANDBERG 6000MXP - Manual (Page 53)

53 D 13887.08
MAY 2008
TANDBERG 3000 MXP & 6000 MXP
REFERENCE GUIDE FOR SYSTEM INTEGRATORS
EXAMPLE
xpreferences completepath on
OK
xstatus call 1
*s Call 1 (status=Synced, type=Vtlph, protocol=H323, direction=Outgoing, logTag=2):
*s Call 1 CallRate: 768
*s Call 1 RemoteNumber: “558458”
*s Call 1 Mute: Off
*s Call 1 Microphone: Off
*s Call 1 Duration: 527
*s Call 1 MuteOutgoing: Off
*s Call 1 Channels 1 (type=Incoming):
*s Call 1 Channels 1 Rate: 768
*s Call 1 Channels 1 Restrict: Off
*s Call 1 Channels 1 Encryption (status=Off): /
*s Call 1 Channels 1 Audio (status=Active):
*s Call 1 Channels 1 Audio Protocol: G722
*s Call 1 Channels 1 Audio Rate: 64
*s Call 1 Channels 1 Video 1 (status=Active):
*s Call 1 Channels 1 Video 1 Protocol: H264
*s Call 1 Channels 1 Video 1 Resolution: CIF
*s Call 1 Channels 1 Video 1 Rate: 704
*s Call 1 Channels 1 Video 2 (status=Inactive): /
*s Call 1 Channels 1 Data (status=Inactive): /
*s Call 1 Channels 2 (type=Outgoing):
*s Call 1 Channels 2 Rate: 768
*s Call 1 Channels 2 Restrict: Off
*s Call 1 Channels 2 Encryption (status=Off): /
*s Call 1 Channels 2 Audio (status=Active):
*s Call 1 Channels 2 Audio Protocol: G722
*s Call 1 Channels 2 Audio Rate: 64
*s Call 1 Channels 2 Video 1 (status=Active):
*s Call 1 Channels 2 Video 1 Protocol: H264
*s Call 1 Channels 2 Video 1 Resolution: CIF
*s Call 1 Channels 2 Video 1 Rate: 704
*s Call 1 Channels 2 Video 2 (status=Inactive): /
*s Call 1 Channels 2 Data (status=Inactive): /
*s/end
OK
The following should be observed:
Complete Path formatting is recommended for easy •
parsing
All lines are prefixed with • *s (for status), *e (for event),
or *l (for historylog)
The complete path to an element is supplied on all lines •
The parser can work line by line •
Root-element end is designated by a *s/end (*e/end or •
*l/end respectively).
NOTE! Complete Path formatting is enabled by: “ xprefer-
ences completepath on ”, described later in this section of
the User Guide.
NOTE! the xpreferences is a session specific command and
must be issued every time the control application connects
to the codec.
XACLI – Status Type Commands – Complete Path Formatting
About the TANDBERG API
About Complete Path formatting
XACLI supports three different formattings for status
information:
Default XACLI formatting, provides good human •
readability, compact format. However, a custom parser
must be used
Complete Path formatting. Recommended when parsing •
the information line by line.
XML formatting – to be used when using an XML-parser. •
About Status Type Commands Formatting
