159
TANDBERG 3000 MXP & 6000 MXP
REFERENCE GUIDE FOR SYSTEM INTEGRATORS
Command Information
D 13887.08
MAY 2008
Required parameters are identified by an (r) appended to the parameter name. The (r) appears in this table for your information only and shall not be included when writing the commands – see the column Example for an illustration of this. Empty lines in the examples provided may have been removed to save space in the tables.
Command Description Parameters Result parameters
when OK
Result parameters
when error
Example
LocalEntryAdd Command used to
add a new entry to the
Directory stored locally.
The entry is stored in
the first vacant position
in the Directory. Name:
The entry’s name.
Number:
The entry’s number.
SecondNumber:
The entry’s second number (2XH221
number).
SubAddress:
The entry’s sub address.
CallRate: 2xh221/64/128/
192/256/320/384/512/768/115
2/1472/1920/2560/3072/4096/
H0/Max/Auto>
The callrate to use when calling this
entry.
Restrict:
Whether to use restrict or not when
calling this entry.
NetProfile: <1..7>
The Net Profile to use when calling
this entry.
LocalEntryId:
<1..200>
Reference to the
Directory position
the entry is stored.
As above xcommand localentryadd name:”John Galt”
number:123
*r Result (status=OK):
LocalEntryId: 17
*r/end
OK
LocalEntryDelete Command used to
delete an entry in the
locally stored Directory. LocalEntryId (r) : <1..200>
Reference to the entry to delete.
None As above xcommand localentrydelete localentry-
id:66
*r Result (status=OK):
*r/end
OK
MessageBoxDelete Command used to
delete a message box
on the screen. None None As above xcommand messageboxdelete
*r Result (status=OK):
*r/end
OK
LocalEntryAdd — MessageBoxDelete
