R0E530640MCU00 User’s Manual 3. Tutorial
REJ10J1733-0100 Rev.1.00 Apr. 01, 2008
Page 56 of 229
3.17.1 Showing the Trace Information Acquired by Fill Until Stop
The free trace facility acquires trace information successively from when the user program starts running till when it breaks.
(1) Clear all break conditions. Click the right mouse button anywhere in the Trace window and choose Acquisition from the
context menu that is displayed. The Trace conditions dialog box shown below will be displayed. Check to see that the
selected trace mode is Fill until stop. Click the Close button.
Figure 3.30 Trace conditions dialog box (free trace)
