R0E530640MCU00 User’s Manual

5. Debugging Functions

REJ10J1733-0100 Rev.1.00 Apr. 01, 2008
Page 198 of 229



5.14.3 Setting an Access Protected Area
Follow the procedure described below to set an access protected area.

(1) From the Hardware Break dialog box

1. Select the Exception check box on the Hardware Break sheet and then click the Detail button.

Figure 5.138 Hardware Break dialog box


2. The Exception page shown below will appear. Click the Detail button to the right of the Violation of access protection check

box.

Figure 5.139 Hardware Break dialog box
