R0E530640MCU00 User’s Manual 5. Debugging Functions
REJ10J1733-0100 Rev.1.00 Apr. 01, 2008
Page 101 of 229
(1) From the Editor or the Disassembly window
1. Check to see that the Editor or the Disassembly window that is currently open includes the position at which you want to set
a software breakpoint.
2. In the S/W Breakpoints column, double-click the line where you want the program to stop.
Figure 5.19 Editor window
Or you use the method described below to set a breakpoint. Select Toggle Breakpoint from the context menu or press the F9
key on the keyboard.
3. When a software breakpoint is set, a red circle [ ] is displayed at the corresponding position in the S/W Breakpoints
column of the Editor or the Disassembly window.
Figure 5.20 Editor window
Double-clicking one more time removes the breakpoint.
