R0E530640MCU00 User’s Manual

2. Setup

REJ10J1733-0100 Rev.1.00 Apr. 01, 2008
Page 30 of 229


2.8 Selecting Clock Supply

2.8.1 Clocks
You can choose a clock supplied to the evaluation MCU by the Emulator tab in the Configuration properties dialog box of the
emulator debugger. Table 2.1 shows the clocks and their initial settings.

Table 2.1 Clock supply to the MCU

Clock

Display of

emulator debugger

Description Default

setting

Emulator

IC17 mounting oscillator module

Yes

User

Oscillator circuit on the user system

-

Main (X

IN

-X

OUT

)

Generate

Internal generator circuit

(1.0--20.0 MHz)

-

Emulator

Internal oscillator circuit

(32.768 kHz)

Yes

Sub (X

CIN

-X

COUT

)

User

Oscillator circuit on the user system

-


IMPORTANT

Notes on Changing the Clock Supply:

z

The clock supply can be set by the Configuration properties dialog box when starting up the emulator debugger

or inputting emulator_clock command on the Command Line window.
