R0E530640MCU00 User’s Manual
7. Hardware Specifications
REJ10J1733-0100 Rev.1.00 Apr. 01, 2008
Page 219 of 229
7.4 External Dimensions
7.4.1 External Dimensions of the E100 Emulator
Figure 7.2 shows external dimensions of the E100 emulator.
W: 73mm
D: 184mm
H: 132mm
Figure 7.2 External dimensions of the E100 emulator
