R0E530640MCU00 User’s Manual

6. Troubleshooting (Action on Error)

REJ10J1733-0100 Rev.1.00 Apr. 01, 2008
Page 211 of 229


6. Troubleshooting (Action on Error)

6.1 Flowchart to Remedy the Troubles

Figure 6.1 shows the flowchart to remedy the troubles from when power to the emulator is activated until the emulator
debugger starts up. Check this while the user system is disconnected. For the latest FAQs, visit the Renesas Tools Homepage.

http://www.renesas.com/tools

Turning on emulator

LED display of emulator

1. Check the connection of power supply cable.
See 2.5 Connecting the Emulator Power Supply.

Device setting dialog box

of emulator debugger

1. Check the operating environment etc. of the emulator
debugger.
See “5.1 Setting Up the Emulation Environment.

2. Reinstall the emulator debugger.

Configuration properties dialog

box of emulator debugger

See “6.3.(2) Configuration Properties Dialog Box Does Not
Appear at Emulator Debugger Startup
.

Editor window of emulator

debugger displayed

See “6.3.(4) Errors Occur at Emulator Debugger Startup.

Emulator debugger startup completed

Normal

Normal

Normal

Normal

Not normal

Not normal/Error displayed

Not normal/Error displayed

Error displayed

Connecting dialog box of

emulator debugger

See “6.3.(3) Errors Occur at Connecting Dialog Box.

Normal

Not normal/Error displayed


Figure 6.1 Flowchart to remedy the troubles
