R0E530640MCU00 User’s Manual

1. Outline

REJ10J1733-0100 Rev.1.00 Apr. 01, 2008
Page 20 of 229


1.4 Specifications

Table 1.5 lists the specifications of the R0E530640MCU00.

Table 1.5 Specifications of the R0E530640MCU00

Applicable MCU

M16C/60 Series M16C/64 Group MCUs with 512 KB ROM

Applicable MCU mode

Single-chip mode, memory expansion mode, microprocessor mode

Maximum ROM/RAM capacity

1. Internal flash ROM: 8KB+16KB+512KB

0E000h--0FFFFh, 10000h--13FFFh, 80000h--FFFFFh

2. Internal RAM: 31KB

00400h--07FFFh

Maximum operating frequency

Power supply voltage: 2.7--5.5V 25MHz (with PLL)
(Emulation memory 0wait: 12MHz, 1wait or more: 25MHz)

Software break

4096 points (uses RAM for break point capability before execution)

Hardware break

16 points (Execution address, bus detection, interrupt, external trigger signal)

Combination, pass count

- Cumulative AND/OR/status transition
- 255 pass counts

Exception event detection

Violation of access protection/task stack access violation/OS
dispatch/initialization omitted

Real-time trace

192bits × 4M cycles
(Address, data, status, CPU status, bus status, target status, task ID, time stamp, 32
external trigger inputs)

Trace mode

Fill until stop/full/point and delay/repeat (free)/repeat (full)

Trace extract/delete

Capture/Do not Capture by events
or
Specified data access instruction extraction/trace extraction before and after point

Real-time RAM monitor

- 16,384 bytes (512 bytes × 32 blocks)
- Data/last access

Time measurement

- Execution time between program start and stop
- Maximum/minimum/average execution time and pass counts of specified eight

sections

- Count clock: Equal to MCU Clock or 10ns—1.6us

Coverage measurement

2 MB (256 KB × 8 blocks)

Profile

1 MB (128 KB × 8 blocks)

Connection to user system

100-pin 0.65mm pitch QFP

R0E0100TNPFJ00

100-pin 0.5mm pitch LQFP

R0E0100TNPFK00

Emulator power supply

Supplied from included AC adapter (power supply voltage: 100--240 V, 50/60 Hz)
