Ricoh Aficio Copy Machine 180 - Manual (Page 90)

Changing the Paper Size
73
3
to the paper size you want to use.
Note
❒ When pressing the levers, push
them together.
F
Adjust the paper size selector.
Note
❒ The available paper sizes on the
paper size selector are shown
below. If the paper size you
need is not there, see “11.Special
Pap. Size” in the System Set-
tings.
• Metric version: A3 L , A4 KL ,
A5 K , 8 1 /
2
" x 11" K , 8" x 13" L
• Inch version: 11" x 17" L ,
8 1 /
2
" x 14" L ,8 1 /
2
" x 11" KL ,
8 1 /
2
" x 13" L ,A4 K
Tray 2, 3
A
Make sure that the paper tray is
not being used.
B
Pull the paper tray, then remove
papers in it.
C
Square the paper and set it in the
tray.
Important
❒ Do not stack paper over the lim-
it mark.
Note
❒ Shuffle the paper before setting
in the tray.
D
Unlock the lever.
E
While pressing the release levers
on the front and rear guides, slide
the front and rear guides to the
