NetWare Configuration
34
3
L
Create a printer as follows.
A In the
[Available Options] menu, select [Print Server Information] .
B To create a new print server, press {
Insert } and input a print server name.
If you use an currently defined print server, select one of the print servers
shown in the
[Print Server] list.
Important
❒ Use the same name as that specified in the NIB Setup Tool. (Step H-A).
C In the
[Print Server Information] menu, select [Print Server Configuration] .
D In the
[Print Server Configuration menu] , select [Printer Configuration] .
E Select the printer which is indicated as “Not Installed”.
F If you change the name of the printer, input a new name.
A name "Printer x" is assigned to the printer. x stands for the number of the
selected printer.
G As Type, select
[Remote Parallel, LPT1] .
The IRQ, Buffer size, Starting form, and Queue service mode are automat-
ically configured.
H Press {
Esc }, and click [Yes] in the confirmation dialog.
I Press {
Esc } to return to the [Print Server Configuration Menu] .
M
Assign print queues to the created printer as follows.
A In the
[Print Server Configuration Menu] , select [Queues Serviced By Printer] .
B Select the printer created in the Step L.
C Press {
Insert } to select a queue serviced by the printer.
Note
❒ You can select more than one queue at a time.
D Follow the instructions on the screen to make other necessary settings.
When you have finished the above steps, make sure that the queues are as-
signed.
N
Press { Esc } until “Exit?” appears, and select [Yes] to exit PCONSOLE.
O
Turn the printer power off and on.
Note
❒ To confirm if the printer is configured correctly, enter as follows from the
command prompt.
F:> USERLIST
❒ If the printer works as configured, the name of the print server appears as
an attached user.
