Ricoh Aficio Copy Machine 180 - Manual (Page 585)

Appendix
200
10
SPECIFICATIONS
❖ ❖ ❖ ❖ Power Consumption
Standard G3
Resolution 8
×
3.85/mm•200
×
100 dpi (Standard), 8
×
7.7/mm•200
×
200 dpi (Detail), 8
×
15.4/mm
(Fine: Optional Expansion Memory re-
quired), 16
×
15.4/mm•400
×
400 dpi (Super
Fine: Optional Expansion Memory required)
Transmission Time 3 seconds at 28,800bps, Standard resolution
Data Compression MH, MR, MMR, JBIG (Fux Function Upgrade
Option required)
Maximum Original Size Standard size: A3/DLT Irregular size: 304
×
432 mm
Maximum Scanning Size 297 mm
×
1,200 mm/11"
×
47"
Print Process Printing on standard paper using the laser
Transmission Speed 33,600/31,200/28,800/26,400/24,000/
21,600/19,200/16,800/14,400/12,000/9,600/
7,200/4,800/2,400 bps (auto shift down sys-
tem)
Transmission 107W
Reception 102W
Printing (Average) 295W
Standby mode 103W
Energy Saving mode 24W
Maximum power consumption 1200W
