RS232 PC-FAX EXPANDER Type 185 USER’S GUIDE
19
E
n
g
lis
h 10.2 MEMORY TRANSMISSION REPORTS
Memory transmission reports include a new mode name to identify memory trans-
missions from the PC: PC MEMORY TX.
RESULT REPORT
* * * COMMUNICATION RESULT REPORT (JUL. 23. 1999 1:01PM) * * *
1) TTI1 XYZ COMPANY
2) TTI2 Head Office
Failure Report
* * * COMMUNICATION RESULT REPORT (JUL. 23. 1999 5:10PM) * * *
1) TTI1 XYZ COMPANY
2) TTI2 Head Office
10.3 USER PARAMETER LIST
User Parameter Switch 20 and 21 appears on the User Parameter List (User tool
keys).
* * USER PARAMETER LIST (JUL. 23. 1999 10:00AM) * * *
1) TTI1 XYZ COMPANY
2) TTI2 Head Office
FILE MODE OPTION ADDRESS(GROUP) RESULT PAGE
004 PC MEMORY TX TOKYO OFFICE OK P. 1
REASON FOR ERRORS
1) HANG UP LINE FAIL 2) BUSY
3) NO ANSWER 4) NO FACSIMILE CONNECTION
FILE MODE OPTION ADDRESS(GROUP) RESULT PAGE
008 PC MEMORY TX NEW YORK OFFICE E-2)2)2)2)2) P. 1
REASON FOR ERRORS
1) HANG UP LINE FAIL 2) BUSY
3) NO ANSWER 4) NO FACSIMILE CONNECTION
•
USER SWITCH
•
(SW20) TR29
PC TX Mode Immediate TX * Memory TX
TTI ON * OFF
CHECKERED MARK PC ON * OFF
(SW21) TR29
PC RX Mode Selection * ON OFF
PC RX Mode PC Direct RX * PC * PC+FAX
Image Density (Lighter) * 1 2 3
Image Density (Darker) 5 6 * 7
