Ricoh Aficio Copy Machine 180 - Manual (Page 268)

NetWare 3.x - Advanced Settings
33
3
E
Select the IPX address of the Network Interface Board which is to be con-
figured by clicking it, and click
[Next >] .
Note
❒ If you don't know which Network Interface Board you are configuring,
print the Configuration Page using the printer's operation panel, and select
the MAC address that is on the page.
F
Confirm that the MAC and IPX addresses are correct, and click [Finish] .
The [NIB Setup Tool] window appears.
G
Click [Configure] .
The property sheet appears.
H
Click the [NetWare] tab, and make the following settings.
A In the
[Print Server Name] box, input the name of the print server.
B In the
[File Server Name] box, input the name of the file server in which a
print server is to be created.
Click [Browse] to select a file server among those listed in the Browse dia-
log.
C In the
[Print Server Operation Mode] group, click [As Print Server] .
D Click
[OK] to close the property sheet.
E After a confirmation dialog appears, click
[OK] .
I
In the [NIB] menu, click [Exit] to exit the NIB Setup Tool.
J
Input “PCONSOLE” from the command prompt.
F:> PCONSOLE
K
Create a print queue as follows.
Note
❒ If you use a currently defined print queue, proceed to the step L.
A In the
[Available Options] menu, select [Print Queue Information] .
B Press {
Insert } and input a print queue name.
C Press {
Esc } to return to the [Available Options] menu.
