USER’S GUIDE RS232 PC-FAX EXPANDER Type 185
18
10 REPORTS AND LISTS
10.1 TRANSMISSION CONFIRMATION REPORT - JOURNAL
For more details, refer to “Printing the TCR” or “Pringintg the Journal” in
the fax machine manual.
RS232 PC-FAX EXPANDER transmissions and receptions are recorded on the
TCR(Transmission Confirmation Report). They are identified with the new sym-
bol.
* * * TCR (July 23. 1999 5:15PM) * * *
1) TTI1 XYZ CO MPANY
1) TTI2 Head Office
Transmit Files for July 23
File 1 (9:00AM) G3 immediate transmission from fax machine to New York
File 2 (1:00PM) G4 memory transmission (broadcasting) from PC to Boston and
Chicago
File 4 (2:10PM) G3 memory transmission failure from PC to New York
Receive Files for July 23
File 3 (1:40PM) G3 memory reception to PC from Toronto
File 5 (3:30PM) G3 memory reception to fax machine from New York
* : PC
Date Time Destination Mode TX-Time Page Result Pers. Name File No.
Jul 23 9:00AM NEW YORK G3ITSM 0’20” P. 3 OK 0001
1:00PM PC ----> PCTS 0’58” P. 2 OK 0002
1:00PM BOSTON G3ITESM* 0’35” P. 2 OK 0002
1:02PM CHICAGO G4TSM* 0’30” P. 2 OK 0002
2:10PM PC ----> PCTS 0’15” P. 2 E 0004
2:10PM NEW YORK G3TSM* 0’15” P. 1 OK 0004
Date Time Destination Mode RX-Time Page Result Pers. Name File No.
Jul 23 1:40 TORONTO G3IRES 0’40” P. 1 OK 003
Jul 23 1:40 ----> PC PCRS 0’40’ P. 1 OK 003
Jul 23 3:30 NEW YORK G3IRES 0’25” P. 1 OK 005
TX 000003 RX 000002
# : Batch C : Confidential $ : Transfer P : Polling
M : Memory L : Send Later @ : Forwarding E : Ecm
S : Standard D : Detail F : Fine u : Super Fine
> : Reduction * : PC
