RS232 PC-FAX EXPANDER Type 185 USER’S GUIDE
17
E
n
g
lis
h 9 PRINTING AT THE FAX MACHINE
To use your fax machine as a printer, follow your PC faxing application's proce-
dures for faxing documents from a Windows application.
When the dialing dialog box appears, use the special four-digit fax dialing num-
ber, 0 0 0 0, to send the document to the fax machine where it will be printed. No
other settings are necessary.
From the Windows application :
1. Choose your faxing application as your printer.
2. Open the document you want to print.
3. Select the Print command and print options.
4. The PC fax application dialog box appears : Dial 0 0 0 0.
5. Click Start (or Send).
MODEM
DIU : The Digital Interface Unit, or RS232 Port
DCR : The Data Compression/Reconstruction Unit
FAX WITH PC-FAX EXPANDER
DIU
(RS232 Port)
MEMORY
PRINT
DCR
