Setting Up Your Server 3-19
17. Install the other end of the cable arm on the arm bracket installed in step 16.
„ For the distance between the mount faces at the front and rear of the rack being 700 mm:
Fix the arm bracket with two screws D and two washers B at the position shown in the
figure below.
„ For the distance between the mount faces at the front and rear of the rack being 743 mm:
Fix the arm bracket with four screws D and four washers B at the position shown in the
figure below.
Arm bracket (900)
Arm bracket (900)
