Configuring Your Server 4-3

Description on On-Screen Items and Key Usage

Use the following keyboard keys to work with the SETUP utility. (Key functions are also listed at
the bottom of the screen.)

Cursor (↑, ↓):

Selects an item on the screen. The highlighted item is currently
selected.

Cursor (←, →):

Selects the Main, Advanced, Security, System Hardware, Boot, or
Exit menu.

and +:

Changes the value (parameter) of the selected item. When a
submenu option (an option preceded by "

³

") is selected, these

keys are disabled.

Enter

Press Enter to select (determine) parameters.

Esc

Displays the previous screen.

F1:

Press F1 when you need help on SETUP operations. The help
screen for SETUP operations appears. Press Esc to return to the
previous screen.

F9:

Sets the parameter of the currently displayed item back to the
factory set parameter.

F10:

Sets the parameter back to the one stored by the server before the
SETUP utility was started.

Indicates the current menu.

Indicates there
are submenus.

Setup item menu

Online help
window

Parameter (high-lights upon selection) menu

Explanation of key functions
