254 Appendix B Configuration Examples
Table 57
LD 22–MS_CONV package
Prompt Response Description
REQ prt
TYPE pkg 408
Screen output:
MS_CONV 408
5 Ensure that the VSID and the ELAN ID are greater than or equal
to 32 and that the SECU parameter is configured to YES for ELAN
and for VAS configuration.
Table 58
LD 22–Check VSID and ELAN ID configuration
Prompt Response Description
PT2000
REQ prt
TYPE vas
VSID 032
DLOP
Screen output:
ELAN 032
SECU YES
INTL 0001
MCNT 9999
6 In LD 20, confirm that STRI/STRO is WNK for SIP Trunk
configuration.
ATTENTION
The screen output shown here may differ, depending on the setup used.
Table 59
LD 20–SIP Trunk configuration
Prompt Response Description
PT0000
REQ prt
TYPE tnb
TN 156 0 0 0
