134
Configuration
5
In the FQDN box, make sure the FQDN listed matches that of the
Mediation Server you have selected.
6
Open a command prompt, change to the root directory, and type
nslookup
and (FQDN of the server) using the FQDN displayed on
the Mediation Server General tab, and then press Enter.
7
From the list of IP addresses displayed in the Communications
Server listening IP address list, select the IP address returned in
. If the IP address selected, does not match the IP address
in
, Communications Server traffic will be directed toward
an interface that is not listening for such traffic and away from the
one that is.
8
From the list of two IP addresses displayed in the Gateway listening
IP address list, select the other IP address (can be a media gateway
or the Communication Server 1000).
9
From the A/V Edge Server list, select the A/V Edge Server that hosts
the A/V Authentication Service for this Mediation Server.
10
In the Default location profile list, select the default location profile
for this Mediation Server
11
In Media port range accept the default range of 60,000 to 64,000.
12
Click the Next Hop Connections tab.
13
On the Next Hop Connections tab under Office Communications
Server next hop. In the FQDN list, select the FQDN of the next-hop
internal server. This server could be a Director or pool. In the Port
box, accept the default of 5061 for TLS.
14
On the Next Hop Connections tab under PSTN Gateway next hop. In
the IP address box, specify the IP address of the OCS Proxy where
the MCM runs. In the Port box, accept the default of 5060 for TCP.
15
Click OK.
—End—
MCM 3.0 configuration
The Multimedia Convergence Manager (MCM) is a software component that
Nortel provides to enable voice connectivity between CS 1000 clients and
the Office Communications Server (OCS) 2007 clients. MCM consists of
the following modules:
•
Call Processing Service
Nortel Communication Server 1000
