Standard Edition 253
Table 56
LD 22––check for licenses
Prompt Response Description
REQ prt
TYPE slt
Screen output:
ANALOGUE TELEPHONES 32767 LEFT 32767 USED 0
CLASS TELEPHONES 32767 LEFT 32767 USED 0
DIGITAL TELEPHONES 32767 LEFT 32767 USED 0
DECT USERS 32767 LEFT 32767 USED 0
IP USERS 32767 LEFT 32756 USED 11
BASIC IP USERS 32767 LEFT 32767 USED 0
TEMPORARY IP USERS 32767 LEFT 32767 USED 0
DECT VISITOR USER 10000 LEFT 10000 USED 0
ACD AGENTS 32767 LEFT 32767 USED 0
MOBILE EXTENSIONS 32767 LEFT 32767 USED 0
TELEPHONY SERVICES 32767 LEFT 32761 USED 6
CONVERGED MOBILE USERS 32767 LEFT 32767 USED 0
NORTEL SIP LINES 32767 LEFT 32767 USED 0
THIRD PARTY SIP LINES 32767 LEFT 32767 USED 0
PCA 32767 LEFT 32762 USED 5
AST 32767 LEFT 32756 USED 11
ITG ISDN TRUNKS 32767 LEFT 32767 USED 0
H.323 ACCESS PORTS 32767 LEFT 32767 USED 0
AST 32767 LEFT 32761 USED 6
SIP CONVERGED DESKTOPS 32767 LEFT 32767 USED 0
SIP CTI TR87 32767 LEFT 32760 USED 7
SIP ACCESS PORTS 32767 LEFT 32753 USED 14
RAN CON 32767 LEFT 32767 USED 0
MUS CON 32767 LEFT 32767 USED 0
TNS 32767 LEFT 32639 USED 128
ACDN 24000 LEFT 24000 USED 0
AML 16 LEFT 14 USED 2
IDLE_SET_DISPLAY NORTEL
LTID 32760 LEFT 32760 USED 0
RAN RTE 512 LEFT 512 USED 0
ATTENDANT CONSOLES 32767 LEFT 32767 USED 0
BRI DSL 10000 LEFT 10000 USED 0
MPH DSL 100 LEFT 100 USED 0
DATA PORTS 32767 LEFT 32767 USED 0
PHANTOM PORTS 32767 LEFT 32767 USED 0
TRADITIONAL TRUNKS 32767 LEFT 32767 USED 0
DCH 255 LEFT 254 USED 1
4 Also in LD 22, confirm that the MS_CONV package is present (this
package is required).
