Page 142

142
Configuration
an INVITE request providing information about which dedicated Mediation
Server or Mediation Server pool to process this message. The parameter
value for SIP Gateway Endpoint Name is configured in Element Manager
under System, IP Network, Nodes: Servers, Media Cards, Signaling
Server Properties. The MCM contains a predefined list of Mediation Server
addresses associated with a given sip-gw-id . The MCM is then able to
determine what pool is used.
ATTENTION
The SIP Gateway Endpoint Name must match the Mediation Server Pool ID, for
example, OCS2007_NODE_A. See
Figure 46 "Mediation routing table" (page
Figure 57 "Element Manager Signaling Server Properties" (page 165)
.
Figure 46
Mediation routing table
Click the Add button to configure the Mediation Server pool’s IP address.
Click OK.
Incoming Call Processing Parameters
This option refers to incoming
CS 1000 calls to MCM that terminate on Office Communicator. You must
specify the phone context. When the telephone context is defined, mapping
is performed (using CDP or UDP). In the case of a large network, the
telephone context used is UDP, while CDP is used for small networks. You
can use Called Phone Prefix Delete and Insert fields to manipulate digits
received from the CS 1000 prior to mapping.
