226 Troubleshooting
AML traces on the Call Server (SIP CTI only)
In LD 48, activate AML traces on the Call Server (SIP CTI only):
Table 41
LD 48
Prompt Response Description
EDD000 enl msgi 32 Enable incoming AML traces for
ELAN 32
EDD000 enl msgo 32 Enable outgoing AML traces for
ELAN 32
Screen output:
ELAN32 I MTYP=3B IACR TN=0 TIME=18:07:34
ELAN32 IN B1B1BE7A OUT B1B1BE7C QSIZE 00000000
ELAN32 03 20 00 00 00 00 1E 3B 00 0B 00 00 95 01 05 36 02 72 14 E6
ELAN32 0C BF EE 01 FF FF FF 00 00 0F FF 00 00
ELAN32 O MTYP=3C IACS TN=0 TIME=18:07:34
ELAN32 IN B1B1BE8B OUT 00000000 QSIZE 00000000
ELAN32 03 27 00 00 00 00 1E 3C 00 0B 00 00 95 01 05 36 02 72 14 E6
ELAN32 0C BF EE 01 FF FF FF 00 00 0F FF 00 00 37 02 98 C2 AA 01 00
ELAN32 I MTYP=1D SETFTR TN=0 TIME=18:07:34
ELAN32 IN B1B1C6E8 OUT B1B1C6EA QSIZE 00000000
ELAN32 03 16 00 00 00 00 16 1D 00 0B 00 00 46 01 08 36 02 72 14 3F
ELAN32 02 00 00
ELAN32 O MTYP=1D SETFTR TN=0 TIME=18:07:34
ELAN32 IN B1B1C6EE OUT 00000000 QSIZE 00000000
ELAN32 03 1D 00 00 00 00 16 1D 00 0B 00 00 3F 02 98 C2 46 01 08 36
ELAN32 02 72 14 71 01 01 78 02 20 0E
SIP CTI traces on the Signaling Server
In PDT, activate SIP CTI traces on the Signaling Server.
Table 42
SIP CTI trace in PDT
Prompt Response Description
pdt SIPCTITrace on activate SIP CTI trace
pdt SIPCTITraceLevel 1
