Remote Call Control configuration

185

SIP CTI CLID configuration parameters

The SIP CTI CLID parameters are used to adjust the format of phone
numbers for incoming call appearances. For Office Communicator these
settings impact the format of numbers that appear on the incoming call
pop-up for Remote Call Control.

ATTENTION

These settings are independent of the similar SIP GW CLID parameters to allow
independent control of the format of numbers on the incoming call pop-up for
Remote Call Control.

For all public calls (subscriber (for example, NXX in North America), national
(for example, NPA in North America), or international) E.164 fully qualified
numbers are used to represent the caller. This is made possible through
the use of the following parameters:

Country Code

Area Code

Subscriber/Number of Digits to strip

Subscriber/Prefix to insert

National/Number of Digits to strip

National/Prefix to insert

The E.164 format of subscriber calls (NXX) is:

+.

The parameters Subscriber/Number of digits to strip and prefix to insert are
used to modify the format of subscriber numbers presented from the PSTN
due to region specific requirements.

The E.164 format of national calls (NPA) is:

+.

The parameters National/Number of digits to strip and prefix to insert are
used to modify the format of national numbers presented from the PSTN
due to region specific requirements.

Parameter: Dialing Plan

When configured to CDP, no changes are made to CDP numbers from the
Call Server. However, when configured to UDP, the location code prefix and
location code are added as a prefix to CDP numbers to aid in normalization.
When this setting is enabled all user phone numbers in the active directory

Nortel Communication Server 1000

Nortel Converged Office Fundamentals — Microsoft Office Communications Server 2007

NN43001-121

01.03

Standard

Release 5.0

30 April 2008

Copyright © 2005–2008, Nortel Networks

.
