Dial In User Statistics window 89
Model 3120 RAS Administrators’ Reference Guide 7 • Dial In
Dial In User Statistics window
This window shows statistics for individual dial-in users. The headings DSP Link, Interface Link, and WAN
Link, shown in figure 37, pertain to the unique time slot defined for each of these links. For specific details on
the function of access server parameters defined under these sections, refer to each under the access server Con-
figuration Menu.
Figure 37. User Statistics (Call Identification, Session)
The Dial In User Statistics window (see figure 27) is where you can view the following:
• Call Identification information (see “Call Identification” on page 90)
• Session information (see “Session” on page 91)
• PPP statistics (see “PPP Statistics” on page 95)
• IP statistics (see “IP” on page 98)
• Phone information (see “Phone” on page 100)
• Data transfer statistics (see “Data” on page 101)
• Physical layer configuration information (see “Physical Layer” on page 101)
