17 • MFR Version 2 Model 3120 RAS Administrators’ Reference Guide
218 Interregister Signalling
Idle Code (lineSigIdleCode)
Code to indicate that a line is in use.
Forward Seize (lineSigForwardSeize)
Code to indicate there is a desire to use a line.
Back Acknowledge (lineSigBackAck)
Code to indicate there is an agreement to use a line.
Back Answer (lineSigBackAnswer)
Code to indicate a call has been completed.
Minimum Transition Time (lineSigMinTransTime)
The minimum transition time in milliseconds.
Minimum Detection Time (lineSigMinDetectTime)
The minimum detect time in milliseconds.
Protocol Timeout (lineSigProtoTimeout)
The time for a protocol timeout in milliseconds.
Interregister Signalling
This portion of the MFR Version 2 main window contains information described in the following sections.
Called Number
Total Digits (interRegCalledNumDig). The number of digits expected for the called number.
First and Middle Response Code (interRegCalledNumFirst). The code specifying what is done after every
digit is sent except the last for the called number.
Last Response Code (interRegCalledNumLast). The code specifying what is done after the last digit is sent
for the called number.
Calling Number
Total Digits (interRegCallingNumDig). The number of digits expected for the calling number.
First and Middle Response Code (interRegCallingNumFirst). The code specifying what is done after every
digit is sent except the last for the calling number.
Last Response Code (interRegCallingNumLast). The code specifying what is done after the last digit is sent
for the calling number.
Speech Condition Set-up (interRegGroupBAck. The code sent when acknowledging the Group B digit to
set-up speech conditions.
