12 • Ethernet Model 3120 RAS Administrators’ Reference Guide
164 Ethernet Statistics
• linkIndication100M(5) - Ethernet is 100M
• linkIndication100Duplex(6) - Ethernet is 100M full duplex
PrimaryIPAddress (boxEtherBPrimaryIpAddress)
The Primary ethernet IP address.
PrimaryIpMask (boxEtherBPrimaryIpMask)
The primary ethernet IP subnet mask.
PrimaryIpFilters (boxEtherAPrimaryIpFilters)
Filters packets based on the filters assigned to the Primary IP address of the Ethernet port. Enter the Filter ID
of a filter configured under Filter IP. Separate multiple filters using a comma (,).
SecondaryIpAddress (boxEtherBSecondaryIpAddress)
The secondary ethernet IP address.
Note This address is not propagated via RIP.
SecondaryIpMask (boxEtherBSecondaryIpMask)
The secondary IP ethernet IP subnet mask.
SecondaryIpFilters (boxEtherASecondaryIpFilters)
Filters packets based on the filters assigned to the Secondary IP address of the Ethernet port. Enter the Filter
ID of a filter configured under Filter IP. Separate multiple filters using a comma (,).
Technique (boxEtherBTechnique)
Turns ethernet port off and on. The remote access server must be reset for this setting to take effect.
• disable(0) - ethernet port is disabled
• static(1) - ethernet port is turned on. IP address(es) and mask(s) are obtained from data entered under the
Ethernet link.
Ethernet Statistics
This window shows statistics about the selected Ethernet Interface . To reach this window select Statistics from
the Ethernet main window.
Alignment Errors (dot3StatsAlignmentErrors)
The number of frames received that are not an integral number of octets in length and do not pass the FCS check.
