An example section of dialout 133
Model 3120 RAS Administrators’ Reference Guide 8 • Dial Out
Data Compression Protocol (doactCompression)
The modem data compression technique used during this call.
• None—No compression.
• V42bis—Compression is running.
• Stac—Not currently implemented.
Modulation Symbol Rate (doactSymbolRate)
The modulation symbol rate during the call. This is used only when in V.34 and above modulations.
Locally Initiated Renegotiated (doactLocalRenegotiates)
The number of times the local modem has initiated a modem speed renegotiate.
Locally Initiated Retrains (doactLocalRetrains)
The number of times the local modem has initiated a modem carrier retrain.
Remote Initiated Renegotiates (doactRemoteRenegotiates)
The number of times the remote modem has initiated a modem speed renegotiate.
Remote Initiated Retrains (doactRemoteRetrains)
The number of times the remote modem has initiated a modem carrier retrain.
An example section of dialout
1. Display the Dial-Out main window.
— Click on the Modify link.
— Set the TCP port to 24 or some other unused port.
— Set TCP Type to telnet.
— Set Login Technique to Text.
— Click on Submit Query.
2. Display the Authentication main window. Scroll down until Static User Identification is displayed (see
figure 18 on page 42) then click on Static User Identification .
— Refer to section “Adding Static Users” on page 42 to create a static user with dialOut as the service.
— Click on Submit Query.
3. Telnet x.x.x.x aa
where x.x.x.x is the IP of your remote access server and
aa is the port Dial-Out is listening to for connections
4. Log in as the user you made in the static database in step 2.
5. At the OK prompt, type ATDT then a phone number to place an analog call or ATDI then a phone num-
ber to digital 64k ISDN call.
6.
