Routing Information 209
Model 3120 RAS Administrators’ Reference Guide 16 • IP
Adding a static routes to a remote network
Do the following:
1. Under Destination , type the IP address of the remote network for which you want to provide a static route.
2. Type the appropriate subnet mask in the Mask field.
3. Under Gateway , type the IP address of the host that will be forwarding packets to the network you entered
in the Destination field in step 1.
4. Click Add Route.
Note If the destination and subnet mask are incompatible or the Gateway
address is not entered an error screen will appear.
Examples of correct and incorrect routes are shown in table 4.
Advanced…
Enables a route to be attached to an interface. Packets to a network will be routed to that interface, allowing the
gateway IP address to be dynamic.
Table 4. Examples of IP routes
Examples of correct entries Examples of incorrect entries
Destination Mask Destination Mask
192.10.10.11 255.255.255.255 192.10.10.11 255.255.255.0
192.10.10.0 255.255.255.0
178.3.4.32
255.255.255.224
178.3.4.16 255.255.255.240 178.3.4.16 255.255.255.224
