ST & T UPSD3212C User Manual
Features summary
1/163
December 2004
uPSD3212A, uPSD3212C
uPSD3212CV
Flash Programmable System Devices with
8032 MCU with USB and Programmable Logic
FEATURES SUMMARY
■
FAST 8-BIT 8032 MCU
–
40MHz at 5.0V, 24MHz at 3.3V
–
Core, 12-clocks per instruction
■
DUAL FLASH MEMORIES WITH MEMORY
MANAGEMENT
–
Place either memory into 8032 program
address space or data address space
–
READ-while-WRITE operation for In-
Application Programming and EEPROM
emulation
–
Single voltage program and erase
–
100K minimum erase cycles, 15-year
retention
■
CLOCK, RESET, AND SUPPLY
MANAGEMENT
–
SRAM is Battery Backup capable
–
Normal, Idle, and Power Down Modes
–
Power-on and Low Voltage reset
supervisor
–
Programmable Watchdog Timer
■
PROGRAMMABLE LOGIC, GENERAL
PURPOSE
–
16 macrocells
–
Implements state machines, glue-logic,
and so forth
■
COMMUNICATION INTERFACES
–
I
2
C Master/Slave bus controller
–
Two UARTs with independent baud rate
–
Six I/O ports with up to 46 I/O pins
–
8032 Address/Data bus available on
TQFP80 package
–
5 PWM outputs, 8-bit resolution
–
USB v1.1, low-speed 1.5Mbps, 3
endpoints (uPSD3212A only)
Figure 1. Packages
■
JTAG IN-SYSTEM PROGRAMMING
–
Program the entire device in as little as
10 seconds
■
A/D CONVERTER
–
Four channels, 8-bit resolution, 10µs
■
TIMERS AND INTERRUPTS
–
Three 8032 standard 16-bit timers
–
10 Interrupt sources with two external
interrupt pins
■
Single Supply Voltage
–
4.5 to 5.5V
–
3.0 to 3.6V
TQFP52 (T)
52-lead, Thin,
Quad, Flat
TQFP80 (U)
80-lead, Thin,
Quad, Flat
