Link Layer Discovery Protocol
3-191
3
Web – Click LLDP, Configuration. Enable LLDP, modify any of the timing parameters
as required, and click Apply.
Figure 3-114 LLDP Configuration
CLI – This example sets several attributes which control basic LLDP message
timing.
Configuring LLDP Interface Attributes
Use the LLDP Port/Trunk Configuration to specify the message attributes for
individual interfaces, including whether messages are transmitted, received, or both
transmitted and received, whether SNMP notifications are sent, and the type of
information advertised.
Command Attributes
• Admin Status – Enables LLDP message transmit and receive modes for LLDP
Protocol Data Units. (Options: Tx only, Rx only, TxRx, Disabled; Default: TxRx)
• SNMP Notification – Enables the transmission of SNMP trap notifications about
LLDP and LLDP-MED changes. (Default: Enabled)
Console(config)#lldp 4-248
Console(config)#lldp refresh-interval 60 4-250
Console(config)#lldp holdtime-multiplier 10 4-248
Console(config)#lldp tx-delay 10 4-251
Console(config)#lldp reinit-delay 10 4-251
Console(config)#lldp notification-interval 30 4-249
Console(config)#lldp medFastStartCount 6 4-249
Console(config)#exit
Console#show lldp config
LLDP Global Configuation
LLDP Enable : Yes
LLDP Transmit interval : 60
LLDP Hold Time Multiplier : 10
LLDP Delay Interval : 10
LLDP Reinit Delay : 10
LLDP Notification Interval : 30
.
.
.
