14.5.2.44

Port x MAC Interrupt Pending Register (MAC_IPR_x)

This read-only register contains the pending Port x interrupts. A set bit indicates an interrupt has been
triggered. All interrupts in this register may be masked via the

Port x MAC Interrupt Pending Register

(MAC_IPR_x)

Chapter 5, "System Interrupts," on page 49

for more information.

Note:

There are no possible Port x interrupt conditions available. This register exists for future use.

Port0: 0481h

Size:

32 bits

Port1: 0881h
Port2: 0C81h

BITS

DESCRIPTION

TYPE

DEFAULT

31:0

RESERVED
