Installing
Optional
Interfaces
QMS 1725 SLS Print System User's Guide 8-32
3 Snap the two plastic feet to the bottom side of the interface
board on the opposite end from the interface connection
» Note: Your optional interface card may look different than the ones
shown in the illustration.
4 Peel the tape from the bottom of the plastic feet
5 With the plastic feet facing down, insert the interface card
through the connector opening in the metal plate from the
outside of the tray assembly.
» Note: Your optional interface card may look different than the one
shown in the illustration.
6 Using the two screws from the I/O plate you removed in step
2, mount the metal plate on the interface card to the connec-
tor opening.
Connector
opening
Interface
card
