IBM 1725 SLS - Manual (Page 198)

Font and
Emulation
Cards
QMS 1725 SLS Print System User's Guide 8-14
Removing an Optional Font
Use the Administration/Disk Operations/Remove Option to remove
optional fonts from your hard disk. You need the original font card
containing the files. The Remove Option compares the contents of
the card against the contents of the hard disk and then deletes the
matching files from the hard disk.
After you have accessed the Administration/Disk Operations menu,
press the control panel keys in the order shown in the following table.
The printer responds by displaying a status message in the message
window (DSK refers to the hard disk number, and CAR0 and CAR1
refer to the font or card number).
» Note: You may need to press the Next key one or more times to advance
through the list of selections or options.
Key Purpose Message
Select Accesses the Administration/Disk
Operations/Remove Option menu. DISK OPERATIONS
REMOVE OPTION
Select Accesses the Remove Option/Dsk#:
menu. REMOVE OPTION
DSK#: x
Next Scrolls through the list of attached
disks. REMOVE OPTION
DSK: x
Select Selects the disk and accesses the card
address from which removal information
is being read. REMOVE SOURCE
CAR#: x
Select Prompts you to insert the font card in
one of the card slots below the printer’s
media cassette. REMOVE OPTION
INSERT MEDIA
Begins reading data from the card and
removing the appropriate fonts from the
hard disk. This usually takes several
minutes. REMOVE OPTION
READING DATA...
Acknowledges completion of the
installation process. REMOVE OPTION
REMOVE COMPLETE
Menu Exits the Install Option menu and
returns to the Disk Operations menu. DISK OPERATIONS
REMOVE OPTION
