Clearing an output bin media jam – IBM 1725 SLS User Manual
Page 166
Media Jams
QMS 1725 SLS Print System User's Guide
6-20
4
After removing the media, close the fuser assembly rear
door and make sure it is properly in place before closing the
printer or the printer may be damaged.
5
Close the printer top cover.
Clearing an Output Bin Media Jam
Follow these steps to clear a jam from the output area:
1
Open the printer top cover and locate the fuser assembly.
M WARNING: Be careful; the area around the fuser assembly is hot.
ACHTUNG! Verletzungsgefahr! Bei Betrieb wird die Umgebung der
Fixiereinheit heiß.
2
If the media is jammed inside the fuser assembly, grasp the
edge of the media and remove it.
3
If the jammed media has passed completely through the
fuser assembly and is partially visible in the upper output
