Administrative password
Enter the password of this LAN switch blade's telnet or SSH administrator account.
If the user ID and the password of the administrator account for the LAN switch blade were set in [User ID] and [Password],
simply re-enter the same password in this field. In this case, Resource Orchestrator does not check whether the password entered
here matches the password set on the LAN switch blade.
SNMP Community
Enter the SNMP community that was set on this LAN switch blade.
Either select [public] or enter an arbitrary string.
Enter a string of up to 32 alphanumeric characters, underscores ("_"), and hyphens ("-").
3. Click .
The registered LAN switch blade will be displayed in the server resource tree.
Information
For a LAN switch blade PY CB DCB SW 10Gb 18/6/6, check that the following settings are displayed correctly in the resource details
of the LAN switch blade after it has been registered.
- Operation mode (VCS mode and other modes)
- VCS ID and RBridge ID
If a displayed value is incorrect, log in to the LAN switch blade and check that the settings of the VCS ID and RBridge ID are correct.
For the confirmation method, refer to the manual for the LAN switch.
If the settings of the VCS ID and RBridge ID are correct, delete the LAN switch blade and register it again.
Note
A telnet or SSH connection is made when registering a LAN switch blade.
When telnet or SSH (SSH version 2) connection is disabled, enable it.
Refer to the manual of the relevant product.
Some models may have restrictions regarding the number of simultaneous connections. In this case, log out from other connections.
If the connection is unavailable, the following features are also unavailable.
- Registration of LAN switch blades
- Changing of LAN switch blade settings
- Changing and setting the VLAN for LAN switch blades (internal and external connection ports)
- Restoration of LAN switch blades
- Server switchover (changing network settings while a server is switched over)
SSH connection (SSH version 2) can be selected for the following LAN switch blades.
- LAN switch blade PY CB Eth Switch/IBP 10Gb 18/8 (1.00 or later version)
- LAN switch blade PY CB Eth Switch/IBP 1Gb 36/8+2 (4.16 or later version)
- LAN switch blade PY CB Eth Switch/IBP 1Gb 36/12 (3.12 or later version)
- LAN switch blade PY CB Eth Switch/IBP 1Gb 18/6 (3.12 or later version)
- LAN switch blade PY CB DCB SW 10Gb 18/6/6 (2.1.1_fuj or later version)
7.3.4 Configuring VLANs on LAN Switches
On managed LAN switch blades, VLANs should be set on both internal ports (those connected to network interfaces on managed servers)
and external ports (those connected to external, adjacent LAN switches).
