Table 6.8 Physical Server Icons
Icon
Meaning
Server
Spare server
Unregistered server
Maintenance mode server
See
For details on the different physical server statuses, refer to "
When a server blade is used as the admin server, the following admin server icon is displayed.
Table 6.9 Admin Server Icon
Icon
Status
Meaning
Admin server
Indicates the server used as the admin server.
An OS icon is displayed below the physical server icon.
The table below shows the meaning of each OS icon.
Table 6.10 OS Icons
Icon
Meaning
Windows OS
Linux OS
VMware host OS
Hyper-V host OS
Citrix XenServer host OS
Linux Xen host OS
KVM host OS
Information
Clicking on a VM host OS icon displays a detailed list of the VM guests operating on the selected VM host.
For details, refer to "
A user-defined label is displayed with a resource icon below the OS icon.
-
If no label is set
The OS name is displayed.
