- PY CB Eth Switch/IBP 1Gb 36/12
- PY CB Eth Switch/IBP 1Gb 18/6
Network links
The following information is only displayed for LAN switch blades.
Resource Name (left side)
The name of the selected network device is displayed.
I/F (left side)
The port name of the network device is displayed.
I/F (right side)
The interface name of the resource connected to the network device is displayed.
Resource Name (right side)
The name of the resource connected to the network device is displayed.
Note
Information about connections with network devices is not displayed.
A.6.5 Power Monitoring Devices (PDU or UPS) Attributes
General Area
Device name
The name used to identify a PDU or UPS is displayed.
Admin LAN (IP address)
The IP address on the admin LAN is displayed.
Device type
The device type (PDU or UPS) is displayed.
Model
The model name of the PDU or UPS is displayed.
Comments
Comments entered when registering a PDU or UPS are displayed.
Hardware Details Area
Serial number
The serial number of the PDU or UPS is displayed.
Voltage
The voltage supplied to the PDU or UPS is displayed.
Hardware version
The hardware version of the PDU is displayed.
This is not displayed for UPSs.
