SPARC Enterprise M-Series

-

SPARC M10

Memory Size

The total capacity of server memory is displayed.
When using servers other than the following, a hyphen ("-") is displayed.

-

PRIMERGY BX Series Servers

-

SPARC Enterprise M-Series

-

SPARC M10

Admin LAN (MAC address 2)

The MAC address of the network interface used for the HBA address rename setup service or for admin LAN redundancy is
displayed.
Not displayed when SPARC Servers/SPARC Enterprise are selected.
Displayed only for servers other than PRIMERGY BX servers.

Hardware Maintenance Mode

The hardware maintenance mode of the server is displayed.
Displayed only for PRIMEQUEST servers.

Boot option

The boot option setting specified when registering servers is displayed.

See

-

Refer to the Management Blade's manual for details on management blades' product names.

-

Refer to the ServerView Operation Manager manual for details on the server models displayed and obtained from ServerView
Operation Manager.

-

Refer to "11.2 Resource Status" in the "Operation Guide VE" for details on resource statuses.

Hardware Details Area

Server management software

The link to the web interface of a server management software is displayed.
Displayed only for the following servers:

-

PRIMERGY Series

-

PRIMEQUEST Servers

-

SPARC Servers/SPARC Enterprise

Remote Management Controller IP address

IP address of the remote management controller is displayed.
Displayed only for servers other than PRIMERGY BX servers.

I/O Virtualization Management Software

The link to the web interface of external I/O virtualization management software is displayed.
Displayed only if coordinated up with external I/O virtualization management software.

VIOM server profile

The assigned VIOM server profile name is displayed.
Displayed only if managed by VIOM and a server profile has been set.

- 176 -
