CHAPTER 7 DETAILED EXECUTION INSTRUCTIONS

7.131

STM0 (Store Multiple Registers)

The "STM0" instruction accepts registers in the range R0 to R7 as members of the
parameter "reglist" (See Table 7.131-1.) .
Registers are processed in descending numerical order.

STM0 (Store Multiple Registers)

Assembler format:

STM0 (reglist)

Operation:

The following operations are repeated according to the number of registers specified in the
parameter "reglist".

R15 – 4

→ R15

Ri

→ (R15)

Flag change:

N, Z, V, and C: Unchanged

Execution cycles:

If "n" is the number of registers specified in the parameter "reglist", the execution cycles
re

q

uired are as follows.

a × n + 1 cycle

Instruction format:

N

Z

V

C

Table 7.131-1 Bit Values and Register Numbers for "reglist" (STM0)

Bit

Register

Bit

Register

7

R0

3

R4

6

R1

2

R5

5

R2

1

R6

4

R3

0

R7

MSB

LSB

1

0

0

0

1

1

1

0

reglist
