"7.42 DIV3 (Correction when Remainder is 0)" is changed.
( "Instruction bit pattern : 1001 1111 0110 0000" is added. )

137

"7.43 DIV4S (Correction Answer for Signed Division)" is changed.
( "Instruction bit pattern : 1001 1111 0111 0000" is added. )

138

"7.44 LSL (Logical Shift to the Left Direction)" is changed.
( "Instruction bit pattern : 1011 0110 0010 0011" is added. )

141

"7.47 LSR (Logical Shift to the Right Direction)" is changed.
( "Instruction bit pattern : 1011 0010 0010 0011" is added. )

144

"7.50 ASR (Arithmetic Shift to the Right Direction)" is changed.
( "Instruction bit pattern : 1011 1010 0010 0011" is added. )

147

"7.53 LDI:32 (Load Immediate 32-bit Data to Destination Register)" is changed.
( "Instruction bit pattern : 1001 1111 1000 0011

: 1000 0111 0110 0101
: 0100 0011 0010 0001" is added. )

148

"7.54 LDI:20 (Load Immediate 20-bit Data to Destination Register)" is changed.
( "Instruction bit pattern : 1001 1011 0101 0011

: 0100 0011 0010 0001" is added. )

149

"7.55 LDI:8 (Load Immediate 8-bit Data to Destination Register)" is changed.
( "Instruction bit pattern : 1100 0010 0001 0011" is added. )

150

"7.56 LD (Load Word Data in Memory to Register)"is changed.
( "Instruction bit pattern : 0000 0100 0010 0011" is added. )

151

"7.57 LD (Load Word Data in Memory to Register)" is changed.
( "Instruction bit pattern : 0000 0000 0010 0011" is added. )

153

"7.59 LD (Load Word Data in Memory to Register)" is changed.

( "o4"

→ "u4" )

154

"7.60 LD (Load Word Data in Memory to Register)" is changed.
( "Instruction bit pattern : 0000 0111 0000 0011" is added. )

156

"7.61 LD (Load Word Data in Memory to Register)" is changed.
( "Instruction bit pattern : 0000 0111 1000 0100" is added. )

157

"7.62 LD (Load Word Data in Memory to Program Status Register)" is changed.

Flag change: ( "Ri"

→ "R15")

158

"7.62 LD (Load Word Data in Memory to Program Status Register)" is changed.
( "Instruction bit pattern : 0000 0111 1001 0000" is added. )

159

"7.63 LDUH (Load Half-word Data in Memory to Register)" is changed.
( "Instruction bit pattern : 0000 0101 0010 0011" is added. )

160

"7.64 LDUH (Load Half-word Data in Memory to Register)" is changed.
( "Instruction bit pattern : 0000 0001 0010 0011" is added. )

162

"7.66 LDUB (Load Byte Data in Memory to Register)" is changed.
( "Instruction bit pattern : 0000 0110 0010 0011" is added. )
