176
CHAPTER 7 DETAILED EXECUTION INSTRUCTIONS
7.80 STB (Store Byte Data in Register to Memory)
Stores the byte data in "Ri" to memory address "(R13 + Rj)".
■
STB (Store Byte Data in Register to Memory)
Assembler format: STB Ri, @ (R13, Rj)
Operation: Ri
→
(R13 + Rj)
Flag change:
N, Z, V, and C: Unchanged
Execution cycles: a cycle(s)
Instruction format:
Example: STB R3, @(R13, R2)
N Z V C
– – – –
MSB LSB
0 0 0 1 0 0 1 0 Rj Ri
R2
1234567B
0 0 0 0 0 0 0 4
0 0 0 0 0 0 2 1
R2
R3 R3 0 0 0 0 0 0 2 1
2 1
0 0 0 0 0 0 0 4
1234567B
1234567C 1234567C
1 2 3 4 5 6 7 8 R13 R13 1 2 3 4 5 6 7 8
x x
Memory Memory
Before execution After execution
Instruction bit pattern : 0001 0010 0010 0011
