CHAPTER 7 DETAILED EXECUTION INSTRUCTIONS

7.99

Bcc:D (Branch Relative if Condition Satisfied)

This is a branching instruction with a delay slot.
If the conditions established for each particular instruction are satisfied, branch to the
address indicated by "label9" relative to the value of the program counter (PC). When
calculating the address, double the value of "rel8" as a signed extension.
If conditions are not satisfied, no branching can occur.
Conditions for each instruction are listed in Table 7.99-1.

Bcc:D (Branch Relative if Condition Satisfied)

Assembler format:

BRA : D

label9

BV : D

label9

BNO : D

label9

BNV : D

label9

BEQ : D

label9

BLT : D

label9

BNE : D

label9

BGE : D

label9

BC : D

label9

BLE : D

label9

BNC : D

label9

BGT : D

label9

BN : D

label9

BLS : D

label9

BP : D

label9

BHI : D

label9

Operation:

if (conditions satisfied) {

PC + 2 + exts (rel8 × 2)

PC

}

Flag change:

N, Z, V, and C: Unchanged

Table 7.99-1 Branching Conditions

Mnemonic

cc

Conditions

Mnemonic

cc

Conditions

BRA : D

0000

B

Always satisfied

BV : D

1000

B

V = 1

BNO : D

0001

B

Always unsatisfied

BNV : D

1001

B

V = 0

BEQ : D

0010

B

Z = 1

BLT : D

1010

B

V xor N = 1

BNE : D

0011

B

Z = 0

BGE : D

1011

B

V xor N = 0

BC : D

0100

B

C = 1

BLE : D

1100

B

(V xor N) or Z = 1

BNC : D

0101

B

C = 0

BGT : D

1101

B

(V xor N) or Z = 0

BN : D

0110

B

N = 1

BLS : D

1110

B

C or Z = 1

BP : D

0111

B

N = 0

BHI : D

1111

B

C or Z = 0

N

Z

V

C
