background image

177

CHAPTER 7 DETAILED EXECUTION INSTRUCTIONS

7.81

STB (Store Byte Data in Register to Memory)

Stores the byte data in "Ri" to memory address "(R14 + o8)".
The value "o8" is a signed calculation.

STB (Store Byte Data in Register to Memory)

Assembler format:

STB Ri, @ (R14, disp8)

Operation:

Ri

(R14 + o8)

Flag change:

N, Z, V, and C: Unchanged

Execution cycles:

a cycle(s)

Instruction format:

Example:

STB R3, @(R14, 1)

N

Z

V

C

MSB

LSB

0

1

1

1

Ri

o8

12345678

R3

R3

0 0 0 0

0 0 2 1

2 1

12345678

12345679

12345679

1 2 3 4

5 6 7 8

0 0 0 0

0 0 2 1

R14

1 2 3 4

5 6 7 8

R14

Instruction bit pattern :

0111 0000 0001 0011

x x

Memory

Memory

Before execution

After execution
