Page 170

146

CHAPTER 7 DETAILED EXECUTION INSTRUCTIONS

7.52

ASR2 (Arithmetic Shift to the Right Direction)

Makes an arithmetic right shift of the word data in "Ri" by "{u4 + 16}" bits, stores the
result to "Ri".

■

ASR2 (Arithmetic Shift to the Right Direction)

Assembler format:

ASR2 #u4, Ri

Operation:

Ri >> {u4 + 16}

→

Flag change:

N: Set when the MSB of the operation result is "1", cleared when the MSB is "0".

Z: Set when the operation result is "0", cleared otherwise.

V: Unchanged

C: Holds the bit value shifted last.

Execution cycles:

1 cycle

Instruction format:

Example:

ASR2 #8, R3

–

MSB

LSB

F F F F F F F 0

F 0 F F F F F F

N Z V C

CCR

N Z V C

1 0 0 1

0 0 0 0

Instruction bit pattern :

1011 1001 1000 0011

Before execution

After execution
