Identifying FRUs in SPARC Enterprise T5120 Servers

187

The following table identifies the power distribution and fan module components in
the server and points to instructions for servicing them.

TABLE:

Power Distribution/Fan Module Components (SPARC Enterprise T5120 Servers)

Item

FRU

Replacement Instructions

Notes

FRU Name (If Applicable)

1

Power distribution
board/bus bar

“Servicing Power
Distribution Boards” on
page 160

Bus bar is attached to the
PDB with four screws.
If replacing a defective
PDB, you must move the
bus bar to the new board
and program the chassis
serial number using the
setscn

command.

/SYS/PDB

2

Paddle card

“Servicing Paddle
Cards” on page 171

Includes the top cover
interlock switch.

/SYS/CONNBD

3

Power supplies

“Servicing Power
Supplies” on page 129

Two power supplies
provide N+1
redundancy.

/SYS/PS0
/SYS/PS1

4

Air duct

“Remove the Air Duct”
on page 100
“Install the Air Duct” on
page 101

Must be installed to
provide proper cooling
to the system.

N/A

5

Fan modules

“Servicing Fan Modules”
on page 123

At least six fan modules
must be installed in the
server.

/SYS/FANBD0/FM0

*

/SYS/FANBD0/FM1
/SYS/FANBD0/FM2

/SYS/FANBD0/FM3

/SYS/FANBD1/FM0
/SYS/FANBD1/FM1
/SYS/FANBD1/FM2
/SYS/FANBD1/FM3

* A fan module might not be present in this location for some configurations.

† A fan module might not be present in this location for some configurations.

‡ A fan module might not be present in this location for some configurations.

6

Fan power boards

“Servicing Fan Power
Boards” on page 143

Must be removed to
service the paddle card.

/SYS/FANBD0
/SYS/FANBD1
