Servicing Motherboard Components

119

Note –

Make note of the location of expansion cards in PCIe/XAUI risers 0 and 1.

10. Disconnect the motherboard-to-power distribution board ribbon cable.

11. Disconnect the hard drive data cables:

a. Press the latching mechanism on the connector to release the cable plug.

If you have difficulty releasing the cable plug, first push the plug slightly into
the connector, then press the latching mechanism.

b. Keeping the latching mechanism pressed, pull the plug from the connector

on the hard drive backplane.

Caution –

The hard drive data cables are delicate. Ensure they are safely out of the

way when servicing the motherboard.

12. If you are replacing the motherboard, remove the following components:

All FB-DIMMs. Note memory configuration so that you can install the
FB-DIMMs in the replacement motherboard.

SCC Module.

13. Using a No. 2 Phillips screwdriver, remove the four screws that secure the

motherboard assembly to the bus bar.

Caution –

Use care when removing the bus bar screws to avoid touching a heat

sink, which can be dangerously hot.

Note –

Set the four screws aside. You must use these screws to attach the

motherboard to the bus bar during installation.

14. Loosen the captive screw securing the motherboard to the chassis.

The captive screw is green, and is located to the left of the bus bar screws.

15. Using the green handle, slide the motherboard toward the back of the system

and lift it out of the chassis.

Caution –

Some components on the motherboard might be hot. Use caution when

handling the motherboard, especially near the CMP heat sinks.
