146 SPARC Enterprise T5120 and T5220 Servers Service Manual • July 2009
Related Information
■ “Remove the Fan Power Board” on page 143
Servicing the Hard Drive Cage
These topics explain how to remove and install the hard drive cage.
■ “Hard Drive Cage Overview” on page 146
■ “Remove the Hard Drive Cage” on page 146
■ “Install the Hard Drive Cage” on page 149
Related Information
■ “Remove the Hard Drive Backplane” on page 152
■ “Remove the Front Control Panel Light Pipe Assemblies” on page 157
Hard Drive Cage Overview
The hard drive cage is the mechanical assembly that contains the system hard drives,
DVD/USB module, and hard drive backplane.
You must remove the hard drive cage to access the following components:
■ Hard drive backplane
■ Front control panel light pipe assemblies
Related Information
■ “Remove the Hard Drive Cage” on page 146
■ “Install the Hard Drive Cage” on page 149
■ “Remove the Hard Drive Backplane” on page 152
■ “Remove the Front Control Panel Light Pipe Assemblies” on page 157
▼ Remove the Hard Drive Cage
1. Power off the system.
See “Removing Power From the System” on page 60 .
